Surface self colored , painted black,plastic coated and Galvanized
Safety factor:4:1
According to EN818-2 standards
Marked G80 or required by customer at interval of one meter at least
The High-dynamic round steel chains are stamped with the serial number.
| Chain Diameter | Tolerance | Inside Length | Tolerance | Inside Width | Outside Width | Weight of per meter | W.L.L. | M.P.F. | B.F. | 1 MIN |
| Φ Mm inch | mm | P mm | mm | L1 Min mm | Le Man mm | Kg/m | kg | KN | KN | |
| 6 1/4 | ±0.24 | 18 | ±0.5 | 7.8 | 22.2 | 0.8 | 1120 | 28.3 | 45.2 | 4.8 |
| 7 9/32 | ±0.28 | 21 | ±0.6 | 9.1 | 25.9 | 1.1 | 1500 | 38.5 | 61.6 | 5.6 |
| 8 5/16 | ±0.32 | 24 | ±0.7 | 10.4 | 29.6 | 1.4 | 2000 | 50.3 | 80.4 | 6.4 |
| 10 3/8 | ±0.40 | 30 | ±0.9 | 13 | 37 | 2.2 | 3150 | 78.5 | 126 | 8 |
| 13 1/2 | ±0.52 | 39 | ±1.2 | 16.9 | 48.1 | 3.8 | 5300 | 133 | 212 | 10 |
| 16 5/8 | ±0.64 | 48 | ±1.4 | 20.8 | 59.2 | 5.7 | 8000 | 201 | 322 | 13 |
| 18 1-1/16 | ±0.90 | 54 | ±1.6 | 23.4 | 66.6 | 7.3 | 10000 | 254 | 407 | 14 |
| 20 3/4 | ±1.00 | 60 | ±1.8 | 26 | 74 | 9 | 12500 | 314 | 503 | 16 |
| 22 7/8 | ±1.10 | 66 | ±2.0 | 28.6 | 81.4 | 10.9 | 15000 | 380 | 608 | 18 |
| 26 1 | ±1.30 | 78 | ±2.3 | 33.8 | 86.2 | 15.2 | 21200 | 531 | 849 | 21 |
| 32 1-1/4 | ±1.60 | 96 | ±2.9 | 41.6 | 118 | 23 | 31500 | 804 | 1290 | 26 |
